YDLIDAR TG30
 |
Range Frequency 20000Hz |
 |
Scan Frequency 5-12Hz |
 |
Range Distance 0.05-30m |
 |
Scan Angle 360° |
 |
Angle Resolution 0.09-0.22° |
 |
Size Φ75.8*34.7mm |
|
Range Frequency 20000Hz |
|
Scan Frequency 5-12Hz |
|
Range Distance 0.05-30m |
|
Scan Angle 360° |
|
Angle Resolution 0.09-0.22° |
|
Size Φ75.8*34.7mm |
|
ToF(Time of Flight) ranging technology Which is ranging by the time difference of laser emitting and receiving, the ranging precision of ToF lidar does not change with distance, and even have higher accuracy for farther objects ranging. |
 |
 |
360 degree omnidirectional scanning Range module inside rotates 360 degree to obtain surrounding information. |
|
Compact structure, suitable for integration Flat and thin, with height of just 3.47cm, it has greatly optimized the structure of integrated products. |
 |
 |
Enclosed housing, IP65 proof level Enclosed design to protect core range module, enabling range in complex applications outdoors. |
|
Applications Mapping | Obstacle Avoidance | Navigation | Screen Interaction | autonomous photogrammetry | Regional security |
ToF(Time of Flight) ranging technology
Which is ranging by the time difference of laser emitting and receiving, the ranging precision of ToF lidar does not change with distance, and even have higher accuracy for farther objects ranging.
360 degree omnidirectional scanning
Range module inside rotates 360 degree to obtain surrounding information.
Compact structure, suitable for integration
Flat and thin, with height of just 3.47cm, it has greatly optimized the structure of integrated products.
Enclosed housing, IP65 proof level
Enclosed design to protect core range module, enabling range in complex applications outdoors.
|
Applications Mapping | Obstacle Avoidance | Navigation | Screen Interaction | autonomous photogrammetry | Regional security |
